Planar - Planar URP85
85" Diagonal Class UltraRes P Series LED-backlit LCD display - digital signage - 4K UHD (2160p) 3840 x 2160 - direct-lit LED - TAA Compliant
Planar
998-2655-01
N/A
0810069810492
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | Planar URP85 UltraRes P Series - 85" LED-backlit LCD display - 4K - for digital signage - TAA Compliant |
| Product Type | LED-backlit LCD flat panel display |
| Diagonal Class | 85" |
| Commercial Use | Yes - digital signage |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Input Video Formats | 480p, 720p, 1080i, 1080p, 576p |
| Frame Rate & Enhancement Technology | 60 Hz Frame Rate |
| Video Interface | HDMI |
| HDMI Ports Qty | 4 ports |
| Connectivity | LAN |
| PC Interface | DisplayPort |
| LCD Backlight Technology | Direct-lit LED |
| Image Aspect Ratio | 16:9 |
| TV Tuner | No tuner |
| Commercial Features | Metal enclosure |
| Picture Enhancements | 72% Color Gamut NTSC |
| Speaker System | 2 speakers |
| Included Accessories | Remote control, IR sensor |
| Voltage | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 175 Watt |
| Power Consumption Stand by | 0.5 Watt |
| Dimensions (WxDxH) | 74.9 in x 3.5 in x 42.6 in |
| Weight | 127.87 lbs |
| TAA Compliant | Yes |
| Environmental Standards | ENERGY STAR Qualified |
| Manufacturer Warranty | 3-year warranty |
| General | |
| Product Type | LED-backlit LCD flat panel display |
| Power Consumption Operational | 175 Watt |
| Diagonal Class | 85" |
| Commercial Use | Yes - digital signage |
| Series | UltraRes P Series |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Video Interface | HDMI |
| HDMI Ports Qty | 4 ports |
| PC Interface | DisplayPort |
| Modes | Portrait mode, landscape mode |
| Picture Enhancements | 72% Color Gamut NTSC |
| Design | Metal frame, 13mm bezel |
| Cooling System | Fanless |
| Width | 74.9 in |
| Depth | 3.5 in |
| Height | 42.6 in |
| Weight | 127.87 lbs |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - advanced exchange program - 3 years |
| Miscellaneous | |
| Included Accessories | IR sensor |
| Cables Included | HDMI cable - 6.6 ft |
| TAA Compliant | Yes |
| Compliant Standards | FCC Class A certified, RoHS, cTUVus, HDCP 2.2 |
| Power | |
| Power Device | Power supply |
| Input Voltage | AC 100-240 V (50/60 Hz) |
| Power Consumption Stand by | 0.5 Watt |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 104 °F |
| Humidity Range Operating | 20 - 85% RH (non-condensing) |
| Display | |
| Pixel Pitch | 0.4875 mm |
| Color Support | 1000000000 colors |
| Resolution | 3840 x 2160 |
| Display Format | 4K UHD (2160p) |
| Image Aspect Ratio | 16:9 |
| Frame Rate & Enhancement Technology | 60 Hz Frame Rate |
| LCD Backlight Technology | Direct-lit LED |
| Coating | Anti-glare, 1% haze |
| Image Contrast Ratio | 5000:1 |
| Brightness | 500 cd/m² |
| Viewing Angle | 178° |
| Viewing Angle (Vertical) | 178° |
| Response Time | 9.5 ms |
| Backlight Life | 50,000 hour(s) |
| Commercial Features | Metal enclosure |
| Operation Hours / Days | 24 / 7 |
| Additional Features | Quad Screen, Dual Screen, Triple Screen, 10-bit support, picture in picture (no tuner), designed for 24/7 operation |
| Connections | |
| Connector Type | RS-232 ¦ LAN ¦ DisplayPort input ¦ 4 x HDMI input ¦ Audio line-out ¦ SPDIF output ¦ Audio line-in ¦ DisplayPort output ¦ Infrared input |
| Video Features | |
| Input Video Formats | 480p, 720p, 1080i, 1080p, 576p |
| Remote Control | |
| Type | Remote control |
| Audio System | |
| Speaker System | 2 speakers |
| Output Power / Total | 20 Watt |
| Speakers | 2 x main channel speaker - 10 Watt |
| Network & Internet Multimedia | |
| Connectivity | LAN |
| Stands & Mounts | |
| Flat Panel Mount Interface | 600 x 400 mm |
| VESA Compatibility | Yes |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
