Cisco - Cisco Webex Room Bar
Video conferencing device - first light
Cisco
CS-BAR-T-K9
N/A
0889728453974
N/A
New
Product Description
Additional Details
What's Included
| Main Specifications | |
|---|---|
| Product Description | Cisco Webex Room Bar - video conferencing device |
| Device Type | Video conferencing device |
| VoIP Protocols | SIP, H.245, H.323, SRTP |
| Codec | H.263, H.264, H.239, G.711, G.722, G.722.1, G.729, AAC-LD, Opus |
| Dimensions (WxDxH) | 21 in x 2.5 in x 3.2 in |
| Weight | 3.31 lbs |
| Digital Signaling Protocol | H.460.18, H.460.19, H.239, BFCP, SIP, H.245, H.323 |
| Data Compression Protocol | H.263, H.264, G.711, G.722, G.722.1, G.729, H.239 |
| Video Input | Digital video camera - HDMI input, DisplayPort input, HDMI output |
| Audio Input | 4-microphone array - beamforming |
| Networking | Bluetooth, Fast Ethernet, Gigabit Ethernet, Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Power | AC 100-240 V (50/60 Hz) |
| Manufacturer Warranty | 90-day warranty |
| General | |
| Device Type | Video conferencing device |
| VoIP Protocols | SIP, H.245, H.323, SRTP |
| Voice Codecs | G.711, G.722, G.722.1, G.729, AAC-LD, Opus |
| Video Codecs | H.263, H.264, H.239 |
| Quality of Service | IEEE 802.1Q (VLAN), IEEE 802.1p |
| IP Address Assignment | DHCP |
| Security | AES, H.323, TLS, IEEE 802.1X, Secure Shell (SSH), SRTP |
| Network Protocols | NTP, IPv6, HTTP, HTTPS, TLS, Cisco Discovery Protocol (CDP), SSH, DNS, SRTP |
| Width | 21 in |
| Depth | 2.5 in |
| Height | 3.2 in |
| Weight | 3.31 lbs |
| Enclosure Color | First light |
| Expansion / Connectivity | |
| Interfaces | 1 x USB-C / DisplayPort - 24 pin USB-C ¦ 1 x audio / video - HDMI input ¦ 2 x audio / video - HDMI output ¦ 1 x audio - line-in/microphone ¦ 1 x USB 2.0 ¦ 1 x network - Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ 1 x network - Ethernet 10Base-T/100Base-TX/1000Base-T (PoE) - RJ-45 |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 90 days |
| Miscellaneous | |
| Included Accessories | Table stand |
| Compliant Standards | CEC 2.0, AES-128, AES-256, Directive 2014/53/EU, Directive 2014/30/EU, Directive 2014/35/EU, Directive 2011/65/EU, Directive 2002/96/EU, NRTL, FCC CFR47 Part 15 B Class A, FCC CFR47 Part 15 C, FCC CFR47 Part 15 E, FCC |
| Networking | |
| Connectivity Technology | Wireless, wired |
| Data Link Protocol | Bluetooth, Fast Ethernet, Gigabit Ethernet, Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac |
| Network / Transport Protocol | NTP, DHCP, IPv6, HTTP, HTTPs, IPv4, DNS |
| Features | Automatic gain control (AGC), VoIP support, Quality of Service (QoS), DTMF support, URI Dialing, Class of Service (CoS), DiffServ support, 2x2 MIMO technology |
| Compliant Standards | IEEE 802.1Q, IEEE 802.1p |
| Power | |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Power Consumption Operational | 20 Watt |
| Software / System Requirements | |
| Software Included | RoomOS 11 or later |
| Environmental Parameters | |
| Min Operating Temperature | 32 °F |
| Max Operating Temperature | 95 °F |
| Humidity Range Operating | 10 - 90% |
| Audio Input | |
| Type | 4-microphone array |
| Microphone Operation Mode | Beamforming |
| Modem | |
| Digital Signaling Protocol | H.460.18, H.460.19, H.239, BFCP, SIP, H.245, H.323 |
| Data Compression Protocol | H.263, H.264, G.711, G.722, G.722.1, G.729, H.239 |
| Video Input | |
| Type | Digital video camera (color) - integrated |
| Interface Type | HDMI input, DisplayPort input, HDMI output |
| Digital Video Capture Resolution | 3840 x 2160, 1920 x 1080 |
| Video Modes | 1080/60p, 4K/30p |
| Digital Zoom | 5 |
| Features | 120° field of view (horizontal), 1/2.3 CMOS image sensor type, F 2.5 lens aperture, 95° field of view (vertical), face detection, speaker tracking, automatic brightness adjustment, auto white balance, fixed focus, 30Hz frame rate, Acoustic Echo Cancellation (AEC) |
